DL6030 | Pressure/temperature/RH datalogger | range 0-30 psig (200 kPa). | Dwyer
Pressure/temperature/RH datalogger, range 0-30 psig (200 kPa).
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to DL6030
Documents and manuals
Dwyer DL6030 Documents
Overview
Details for DL6030
See catalog product page for full listing
Pressure/temperature/RH datalogger | range 0-30 psig (200 kPa).
Series DL6 Pressure/Temperature/RH Data Logger
Self-Powered, 5-Channel, Store up to 32,768 Readings, Compact
Monitor and troubleshoot HVAC systems, verify energy management systems, or track performance of pneumatically controlled valves with Series DL6 Pressure/Temperature/RH Data Logger. Units include an on-board thermistor for ambient temperature measurement and pressure module. Remote humidity/temperature sensor and plug-in humidity sensor are sold separately. Loggers can store up to 32,768 readings and operate independently from any external power supply with built-in lithium battery. Use Model DL200 Windows® software (sold separately) to quickly program the logger or upload data to the computer.
Specifications
- Series
- DL6 Pressure/Temperature/RH Data Logger
- Category/Type
- Test Equipment
- Type
- Data Loggers
- Series
- DL6 Pressure/Temperature/RH Data Logger
- No. of Channels
- Five; internal thermistor; pressure module (included); plug-in humidity sensor; remote humidity/temperature sensor.
- Internal Thermistor Range
- -40 to 158°F (-40 to 70°C).
- Compensated Temperature Range
- 32 to 158° F (0 to 70°C).
- Memory Size
- 32;768 readings.
- Accuracy
- ±1% FS.
- Clock Accuracy
- ±8 sec/day plus one sampling interval.
- Thermal Accuracy
- ±1% FS.
- Drift
- ±0.2% FS/yr.
- Internal Thermistor Resolution
- 0.7°F (0.4°C); R25 value equal to 10;000Ω.
- Resolution
- 8 bits (1 in 256).
- Sampling Method
- Continuous (First-in; First-out) or Stop when full (Fill-then-stop).
- Sampling Rate
- Selectable from 8 seconds to once every 5 days.
- Ambient Operating Temperature/RH
- -50 to 160°F (-45 to 70°C); 0 to 95% RH; non-condensing.
- Connection
- Removable screw terminal.
- Computer Requirements
- IBM compatible 386 or above and Windows® 3.1 or later with 2MB RAM and 2MB hard drive disk space; one serial port.
- Power Requirements
- 3.6 V TL5134 lithium metal battery; internal; factory replaceable.
- Power Consumption
- 5 to 10 µA.
- Service
- Air and noncorrosive gases.
- Max. Pressure Rating
- 4X rated pressure.
- Housing Material
- PPE & PS (polyphenylene ether & polystyrene).
- Weight
- 5 oz (110 g).
- Agency Approvals
- CE.
