1003W-A1-D | Weatherproof pressure switch | adj. range 5-40 psig (.48-2.8 bar) | approx. deadband (fixed) 2 psig (.14 bar). | Dwyer
Weatherproof pressure switch, adj. range 5-40 psig (.48-2.8 bar), approx. deadband (fixed) 2 psig (.14 bar).
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to 1003W-A1-D
Documents and manuals
Dwyer 1003W-A1-D Documents
Overview
Details for 1003W-A1-D
See catalog product page for full listing
Weatherproof pressure switch | adj. range 5-40 psig (.48-2.8 bar) | approx. deadband (fixed) 2 psig (.14 bar).
Series 1000W Weatherproof Diaphragm Operated Pressure Switches
Visible Setpoint, Fixed Deadband, Pressure Ranges to 1400 psi
With extremely rugged construction the Series 1000W Weatherproof DiaphragmOperated Pressure Switch provides excellent reliability in chemical, petroleum andindustrial plants. Bellville spring movement permits mounting of control in any positionand helps prevent contact chatter. New design also provides high over-pressureprotection. Weatherproof housing is standard.
Product Applications
- Chemical, petroleum, food and drug processing industries
- Process and Industrial applications
- Weatherproof housing is ideal for a wide variety of applications where dust or wateris present
- Spring movement design provides for control in any mounting position and preventscontact chatter reducing false or inconsistent switching
Specifications
- Series
- 1000W Weatherproof Diaphragm Operated Pressure Switches
- Category/Type
- Pressure
- Type
- Single Pressure
- Series
- 1000W Weatherproof Diaphragm Operated Pressure Switches
- Wetted Materials
- See pressure chamber and diaphragm material in model chart.
- Temperature Limits
- -30 to 170°F (-35 to 77°C).
- Pressure Limit
- 3000 psig (206.8 bar).
- Enclosure Rating
- Weatherproof; meets NEMA 4X (IP66).
- Switch Type
- SPDT snap switch.
- Electrical Rating
- 15 A @ 125/250 VAC resistive.
- Electrical Connections
- Screw type.
- Conduit Connection
- 3/4" female NPT.
- Process Connection
- 1/4" female NPT.
- Mounting Orientation
- Any position.
- Set Point Adjustment
- Internal thumbwheel.
- Weight
- 3 lb (1.4 kg).
- Deadband
- See model chart.
- Agency Approvals
- CE; UL.
