G220B-K+LVX24-SR | Globe Valve | 0.75" | 2 Way | 7.5 Cv | w/ Non-Spring | 24V | Modulating | Belimo

Globe Valve | 0.75" | 2 Way | 7.5 Cv | w/ Non-Spring | 24V | Modulating

For fail-safe, modulating control of dampers in HVAC systems. Actuator sizing should be done in accordance with the damper manufacturer’s specifications. The actuator is mounted directly to a damper shaft from 3/8" up to 1/2" in diameter by means of its universal clamp, 1/2" shaft centered at delivery. For shafts up to 3/4" use K6-1 accessory. A crank arm and several mounting brackets are available for applications where the actuator cannot be direct coupled to the damper shaft. The actuator operates in response to a 2...10 V, or with the addition of a 500Ω resistor, a 4...20 mA control input from an electronic controller or positioner. A 2...10 V feedback signal is provided for position indication.
