When to Choose a Fail Safe Pneumatic Interface?

All ACI pneumatic transducers have a fail safe model.

When the installation requires dampers to close quickly on a power failure, or any actuator to assume a fail safe position quickly, ACI has the answer. Look for the FS suffix on ACI pneumatic interfaces.

  1. These are not bleed type interfaces. They consume no air at setpoint and require no increase in the size of the compressor. The controlled, high capacity, three-way branch exhaust valve allows the branch line to drop to zero on a power failure.
  2. Anodized aluminum manifold with gauge port - gauge can be factory installed.
  3. Air handling capacity of 750 scim.
  4. Field selectable input ranges.
  5. 0 -15 psig output (plus feedback).
  6. Manual Override - allows operation checkout before putting in service.
  7. Not position sensitive, mounts at any angle, on snaptrack provided.
Product
Signal Action
Features
PXP2.3FS
Analog to Dual Valve Pneumatic
High capacity supply valve, 750 SCIM, 90-100 micron filter-in-barb provided, 3-way branch valve exhausts on power failure, manual override, field selectable signal input ranges
PWP2.3FS
Pulse to Dual Valve Pneumatic
High capacity supply valve, 750 SCIM, 90-100 micron filter-in-barb provided, 3-way branch valve exhausts on power failure, manual override, field selectable signal input ranges
PTS3.3FS
Floating Point to Dual Valve Pneumatic
High capacity supply and branch valve with 3 Min. to max. change rates available on branch, 750 SCIM, 90-100 micron filter-in-barb provided, 3-way branch valve exhausts on power failure, selectable ramping times

When to Choose a Fail Safe Pneumatic Interface?

See PXP2.3FS
