480 | tekmarNet 4 User Switch - Three Inputs | Tekmar

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to 480

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Tekmar 480 Documents

Datasheet Installation Instructions More Info

Overview

Details for 480

tekmarNet 4 User Switch - Three Inputs

The tekmarNet^® 4 User Switch 480 is a simple 3 button switch that provides an easy way to override system temperatures. With the push of a button, one can put all thermostats and boiler controls into an "unoccupied" or "away" state and take advantage of saving energy when the building is not being used. The buttons on this product are also programmable, allowing the user to experience scenes within their system. The 480 has three demand inputs that can provide access to tekmarNet ^® 4 scenes or setpoint devices from a telephone switch, home automation, or security systems.

Features

3 demand inputs for remote access
tekmarNet^® 4 and tekmarNet ^® 2 compatible
One touch system overrides
3 programmable user buttons
Setback up to 96 thermostats with one button

Specifications

Item Number	480
Brand	Tekmar
Category	tekmarNet Controls
Agency Approvals	CSA C US, meets Class B: ICES & FCC Part 15
Ambient Conditions	Indoor use only, 32 to 122 degrees F (0 to 50 degrees C), RH less than or equal to 92 percent to 104 degrees F (40 degrees C), and 50 percent above 104 degrees F (40 degrees C), Altitude less than 9840 FT (3000 m), Pollution Degree 2
Demand	24 V (ac) or Contact closure
Device Type	tN4 User Switch
Dimensions	4.5" H x 2.75" W x 0.8" D (104 x 43 x 20 mm)
Enclosure Material	White PC+ABS plastic
Power Supply	24 V (ac) plus / minus 10 percent, 50/60 Hz, 2.2 VA
