LAD4RCU | TeSys D, RC transient suppressor, 110 to 250 VAC, for LC1D09 to LC1D38, mounts on right side in cavity | Square D by Schneider Electric

Brand: Square DSKU: LAD4RCU

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to LAD4RCU

Jump to: Overview & Specifications Reviews

Overview Details for LAD4RCU

TeSys D, RC transient suppressor, 110 to 250 VAC, for LC1D09 to LC1D38, mounts on right side in cavity

TeSys D suppressor module, for LC1D09-D38, LC1DT20-DT40 contactors and CAD control relays. To be used with 110-250V AC control circuit voltage, it provides a RC protection limiting the transient voltage to 3 Uc max. Clip-on side mounting, overall size of the contactor is unchanged. Green Premium compliant (RoHS/REACh).

Specifications

Range: TeSys
Device short name: LAD4
Product or Component Type: Suppressor module
product compatibility: 3P LC1D09...D38, 4P LC1DT20...DT40, 4P LC1D098...D258, CAD32, CAD50
Mounting Location: Side
Mounting Mode: By clips
Suppressor technology: RC circuit
[Uc] control circuit voltage: 110...250 V AC
maximum peak voltage: 3 Uc
Net Weight: 0.03 lb(US) (0.012 kg)
standards: IEC 60947-5-1, EN 60947-5-1, CSA C22.2 No 60947-5-1, UL 60947-5-1, GB/T 14048.5
Product Certifications: UL, CSA
IP degree of protection: IP2xIEC 60529
Ambient Air Temperature for Operation: -13…131 °F (-25…55 °C)
Ambient Air Temperature for Storage: -40…176 °F (-40…80 °C)
Category: 22341-CONTACTOR,D,K,&F ACCESS
Discount Schedule: I12
GTIN: 3389110385458
Returnability: Yes
Country of origin: FR
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 0.43 in (1.100 cm)
Package 1 Width: 3.94 in (10.000 cm)
Package 1 Length: 1.97 in (5.000 cm)
Package 1 Weight: 0.49 oz (14 g)
Unit Type of Package 2: S01
Number of Units in Package 2: 70
Package 2 Height: 5.91 in (15.000 cm)
Package 2 Width: 5.91 in (15.000 cm)
Package 2 Length: 15.75 in (40.000 cm)
Package 2 Weight: 2.66 lb(US) (1.207 kg)
Unit Type of Package 3: P06
Number of Units in Package 3: 2240
Package 3 Height: 29.53 in (75.000 cm)
Package 3 Width: 23.62 in (60.000 cm)
Package 3 Length: 31.50 in (80.000 cm)
Package 3 Weight: 107.01 lb(US) (48.539 kg)
Warranty: 18 months
