GS2AEH12 | Switch, TeSys GS, shaft guide for external rotary handle | Square D by Schneider Electric

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to GS2AEH12

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Square D GS2AEH12 Documents

Datasheet More Info

Overview

Details for GS2AEH12

Switch, TeSys GS, shaft guide for external rotary handle

TeSys GS fusible disconnect switches with the use of Class CC or J fuses provide exceptional high short circuit protection. Switches are available from 30A to 800A sizes. SCCR of up to 200 kA are possible with these fusible disconnect switches. This shaft guide is used to guide the shaft form an external rotary handle into the switch. A GS2AE shaft extention will work with this shaft guide. Shaft guide will with GS2AH, GS2AHT, GS2AE, GS2AH and GS2AHT rotary handles. Shaft guide is UL component recognized and CSA certified. Shaft guide meets the requirements of RoHS/REACh making it a Green Premium product.

Specifications

Range: TeSys
Product or Component Type: Guiding support
Accessory / separate part category: Control accessory
range compatibility: TeSys (TeSys GS) GS2AH rotary handle, TeSys (TeSys GS) GS2AHT rotary handle, TeSys (TeSys GS) GS2AE shaft extension, FuPact (FuPacT GS) GS2AH rotary handle, FuPact (FuPacT GS) GS2AHT rotary handle, FuPact (FuPacT GS) GS2AE shaft extension
Type of operating handle: External
Mounting Support: Direct mounting on handle
Shaft cross section: 10 x 10 mm, 12 x 12 mm, 15 x 15 mm
Quantity per Set: Set of 1
Category: 22640-IEC DISCONNECT-GS1,LK3
Discount Schedule: I11
GTIN: 3606480744976
Returnability: Yes
Country of origin: FR
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 1.18 in (3 cm)
Package 1 Width: 3.54 in (9 cm)
Package 1 Length: 4.33 in (11 cm)
Package 1 Weight: 0.99 oz (28 g)
Unit Type of Package 2: S02
Number of Units in Package 2: 25
Package 2 Height: 5.91 in (15 cm)
Package 2 Width: 11.81 in (30 cm)
Package 2 Length: 15.75 in (40 cm)
Package 2 Weight: 2.21 lb(US) (1.002 kg)
