ECPBYV11025E | 2-1/2" BYV Series PVC Body, PVC Disc and EPDM Seals with ECP3 GFPP Actuator | Hayward
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to ECPBYV11025E
Documents and manuals
Hayward ECPBYV11025E Documents
Overview
Details for ECPBYV11025E
2-1/2" BYV Series PVC Body, PVC Disc and EPDM Seals with ECP3 GFPP Actuator
Hayward Flow Control’s industry leading actuation offering and service is now quicker than ever before. By maximizing our LEAN production model and full scale US manufacturing base, Hayward can get your system up and running when it has to. Get any one of the selected automated ball and butterfly valve packages shipped out to you within one business day of ordering.That simple. That easy
Specifications
Item Number | ECPBYV11025E |
Brand | Hayward |
Actuator Series | ECP Series Glass-Filled Polypropylene Electric Actuators |
Actuator Type | Electric |
Category | Actuated Valves |
Category | Actuation & Controls |
Class | ECP Series Automated Butterfly Valves |
Control | On/Off or Proportional |
Enclosure Material | Glass Filled Polypropylene |
Enclosure | NEMA4/4X |
Flow Coefficient (Cv) | 190 |
Housing Material | GFPP |
ISO 5211 Flange & Drive | F07-D11 |
Liner Material | EPDM |
Material | PVC Body |
Medium Temperature Range | 70 ºF |
Method of Operation | Actuated |
Operation | On / Off |
Phase | Single Phase |
Pipe Size | 2-1/2 in |
Pressure Rating at 70°F | 10 bar 150 psi |
Sealing Material | EPDM |
Series | Hayward QuikShip Automated Valves |
Standard Voltage | 24VAC/VDC |
Sub Category | Actuated Valves |
SubCategory | Actuated Butterfly Valves |
SubCategory | ECP Series Automated with BYV Series Butterfly Valves |
Subtype | Automated Valves |
Type | Thermoplastic Valves |
Valve Body Material | PVC |
Valve Disc Material | PVC |
Valve Series | BYV Series Butterfly Valves |
Valve Size | 2-1/2" |
Valve Type | Butterfly |
