F760N | Nylon liquid/particle filter with 1/4" NPT connection and 10.5 in³ internal volume. | Dwyer

Nylon liquid/particle filter with 1/4" NPT connection and 10.5 in³ internal volume.

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to F760N

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Dwyer F760N Documents

Series F700 Catalog Page More Info

Overview

Details for F760N

See catalog product page for full listing

Nylon liquid/particle filter with 1/4" NPT connection and 10.5 in³ internal volume.

Series F700 Nylon Filter

Ideal For Filtering Liquids and Gasses in Low Pressure Systems

The F700 Series of filters is ideal for the filtering of liquids or gasses in low pressure systems. The nylon construction is resistant to harmful components often found in sample streams. Replaceable filter elements remove particles and droplets as small as .01 micron with 95% efficiency.

Specifications

Series: F700 Nylon Filter
Category/Type: Accessories
Type: Filters; Regulators and Lubricators
Series: F700 Nylon Filter
Filtration Efficiency: 95% (removal of .01 micron particles).
Maximum Pressure: 100 psig (6.89 bar).
Maximum Temperature: 120ºF (49ºC).
Max. Flow at 100 psig (6.98 bar): F710N; F711N: 23 SCFM (651 lpm); F760N; F761N: 27 SCFM (765 lpm).
Inlet & Outlet Ports: F710N: 1/8" NPT; F711N; F760N: 1/4" NPT; F761N: 1/2" NPT.
Mounting: In-line only.
Materials of Construction: Complete nylon construction (head; bowl; internals) with a Fluorocarbon (FKM) o-ring seal.
Internal Volume: F710N; F711N: 3.05 in³ (50 cc [mL]); F760N; F761N: 10.5 in³ (172 cc [mL]).
Weight: F710N; F711N: .15 lb (.068 kg); F760N; F760N: .4 lb (.18 kg).
