How to Convert Multiple Signals to Resistance

The DRN3.1 Another Fail Safe Interface in the problem solving arsenal



The DRN3.1 Another Fail Safe Interface in the problem solving arsenal





The DRN3.1 Another Fail Safe Interface in the problem solving arsenal

FAIL SAFE CONNECTIONS TO A FIXED RESISTANCE OR ORIGINAL CONTROLLER

Product
Type
 Features
DRN3.1
Analog, Pulse, or Floating Point to Resistance
Analog inputs of 0-5, 1-5, 0-10, 2-10, 0-15, 3-15 VDC, 0-20 or 4-20 mA. Floating Point rates of change of 30, 45, 60, 90, 120, and 240 seconds. Pulse inputs of .02-5 sec., .1-25.5 sec., .59 to 2.93 seconds, .1 to 10 seconds, .023 to 6 seconds, and 0-10 second Duty Cycle Pulse (sampled in a 10 second window). On a power failure, fails to original controller, or the value of the resistance connected at the failsafe terminals.



See All DRN3.1 Products
