AE-631-101 | Sub-Panel For AE-631 | Schneider Electric

Brand: Schneider ElectricSKU: AE-631-101

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to AE-631-101

Jump to: Overview & Specifications Reviews

Overview Details for AE-631-101

Sub-Panel For AE-631

Charcoal Gray Sub-Panel For AE-631

Application

Control cabinets for mounting of electric, electronic and pneumatic controls.

Specifications

Construction:

Doors, Locking type, with keys, rigidly supported. The doors easily removed for protection on job site installation or mounting of components. See Table 1.
Steel Gauge, See Table 1.
Knockouts, Aligned so that a short nipple may be used
to couple the panels. See Table 1.
Appearance, See Table 1.

Locations: NEMA Type 1 indoor only.

Mounting: Four extruded mounting holes 1/4" (6 mm).

Dimensions: See Table 1.

Accessories:
None.

Maintenance Parts
BYZP-268 Replacement lock for AE-630 thru AE-632
