947142 | 3/8 IN LINE CHECK VALVE VERT OR HORIZ, Valves, 2017 Valves, In Line Check Valve vertical or horizontal | Midland Metal Mfg.

Brand: Midland Metal Mfg.SKU: 947142

The photo is for representation purposes only and may not be a photo of product being purchased.

Overview Details for 947142

3/8 IN LINE CHECK VALVE VERT OR HORIZ, Valves, 2017 Valves, In Line Check Valve vertical or horizontal

Item Number	947142
Brand	Midland Metal Mfg.
Additional Information	3 psi Cracking Pressure; Vertical or Horizontal; 2-1/2 in Length; 2.18 in Height; 3/8-18 Thread Size; 0.620 lb Weight
Body Material	Cast Bronze
Category	Valves
Connection Type	FIP x FIP
Description	In Line Check Valve vertical or horizontal
Domestic/Import	Import
Inlet to Outlet Length	2-1/2 in
Lead-Free/Contains Lead	Contains Lead
Material	Brass
Nominal Size	3/8 in
Opening Size	3/8 in
Port Type	1/8 in NPT Unloader
Pressure Rating	250 psi
Seal Material	PTFE
Section	2017 Valves
Shape	FIP X FIP
Temperature Rating	-40 to 450 deg F
Trim Material	Brass Plug/Stainless Steel Spring/HNBR O-Ring/C360 Machined Brass Cap/Polytetrafluoroethylene Poppet
