F680HD+DRX24-MFT-T | Butterfly Valve | 3" | 2 Way | 302 Cv | w/ Non-Spring | 24V | MFT | Belimo
Butterfly Valve (BFV), 3", 2-way, ANSI Class Consistent with 125, Cv 302 |Configurable Valve Actuator, Non fail-safe, AC/DC 24 V, 2...10 V, terminals, MFT/programmable
Documents and manuals
Belimo F680HD+DRX24-MFT-T Documents
Overview
Details for F680HD+DRX24-MFT-T
Butterfly Valve | 3" | 2 Way | 302 Cv | w/ Non-Spring | 24V | MFT
Butterfly Valve | 3" | 2 Way | 302 Cv | w/ Non-Spring | 24V | MFT
Application
Valve is designed for use in ANSI flanged piping systems to meet the needs of bi-directional high flow HVAC hydronic applications with 0% leakage. Typical applications include cooling tower bypass, primary flow change-over systems, and large air-handler coil control. Valve face-to-face dimensions comply with API 609 & MSS-SP-67, Completely assembled and tested, ready for installation.
Jobsite Note
Valve assembly should be stored in a weather protected area prior to installation. Reference the butterfly valve installation instruction for additional information
Specifications
- Valve specifications
- ANSI Class
- Consistent with 125
- Controllable Flow Range
- 90B0 rotation
- Cv
- 302
- End Connection
- Lug types
- End Fitting
- Flange
- Fluid
- Chilled or hot water up to 60% glycol
- Pattern
- 2-way
- Pressure Independent
- NO
- Valve Size
- 3" [80]
- Actuator specifications
- Actuator Type
- Non fail-safe
- Control Type
- MFT/Programmable
- Degree of Protection
- IP54 NEMA 2 UL Enclosure Type 2
- Electrical Connection
- terminals
- Manual Override
- External push button
- Power Consumption (Holding)
- 3 W
- Power Consumption (Running)
- 12 W
- Running Time (Motor)
- 150 s / 90B0
- Voltage AC/DC
- AC/DC 24 V
