This Programmable Signal Generator:
- Weighs less than 1 pound, including carrying case
- Can duplicate control system signals
- Includes cables and ballistic nylon case with carrying loop
- Saves Setup Time for the Tech Rep
- Generates these signal ranges:
- Analog Current: 0-20 mA, 8 bit, 255 steps
- Analog Voltage: 0 to 10 VDC
- Pulse: 0.01 to 999.99 in seconds, minutes, or hours
- Pulse (Wet): Triac switched 24 VAC from supply voltage
- Pulse (Dry) : Triac switched external 9 to 24 VAC source
- DC Pulse (Wet): Transistor switched 24 VDC from supply circuit
- DC Pulse (Dry) : Transistor switched external 5 to 30 VDC source
