Documents: 36555859

Data sheet PV 34.83

36555859 | PSM03 20...250 bar Vertical flange DIN ISO 163873 | Wika

Brand: WikaSKU: 36555859

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to 36555859

Jump to: Overview & Specifications Reviews

Overview Details for 36555859

PSM03 20...250 bar Vertical flange DIN ISO 163873

Applications

Hydraulics and mobile hydraulics
Pneumatics
Plastics injection moulding machines
General machine building and plant construction
Media: Compressed air, neutral and self-lubricating fluids, neutral gases

Special Features

High reproducibility
High vibration and shock resistance
Setting ranges -0.85 ... -0.15 bar and from 0.2 … 2 bar to 40 … 400 bar
Long service life due to high-quality micro switch
Precise switch point setting with adjustment knob

Description

Model PSM03 mechanical pressure switches in a diaphragm or piston variant open or close a circuit, depending on whether the pressure is dropping or rising. An adjustment knob enables easy, convenient and continuous setting of the required switch point. Optionally, WIKA offers its customers the factory setting of the switch point.

Model PSM03 mechanical pressure switches are employed wherever compressed air, neutral and self-lubricating fluids or neutral gases are used and customers, due to their spatial conditions, have special requirements regarding the installation of the pressure switch.

The high reproducibility of ±2 % of the switch point and the setting via the adjustment knob is interesting for customers for whom precision plays an important part. In addition, the individual orientation of the pressure switch makes the model PSM03 attractive for customers who set value on the adaptation of the switch to their specific space conditions.
