FLT230 | FLT CPVC 30" Single Cartridge Filter for 2-1/2" Cartridges | Hayward

Brand: HaywardSKU: FLT230

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to FLT230

Jump to: Overview & Specifications Reviews

Overview Details for FLT230

FLT CPVC 30" Single Cartridge Filter for 2-1/2" Cartridges

Ideal for skid systems and compact space requirements to filter fine particles from process fluid. For use with 2-1/2” Cartridges. Available in 10", 20" and 30" heights in PVC and CPVC material with ¾” NPT connection. The maximum flow rate per 10" length is 5 GPM. FPM seal is standard. EPDM upon request.

• Available in PVC and CPVC
• FPM O-Ring Cover Seals
• Compact Design
• Ergonomic Hand-Removable Cover
• Integral, Plugged Tap on Cover for Easy Bleeding of Filter Vessel
• Fits One DOE 2-1/2” Cartridge

Specifications

Item Number	FLT230
Brand	Hayward
Body End Connector Material	CPVC / CPVC
Body Material	CPVC
Category	N/A
Class	N/A
Configuration	Simplex
End Connection Material	CPVC
End Connection Type	NPT
Flow Rate	10 GPM
Pipe Size	3/4 in
Pressure Rating	150 PSI
Seal	FPM
Sealing Material	FPM
Series	FLT Series Single Cartridge Filters
Sub Category	N/A
Subtype	Cartridge Filters & Cartridges
Type	Hayward Filtration® & Straining
Vessel Length	30"
